Descrizione
Scheda grafica Point of View GeForce 9800 GTX
- Produttore: Point of View
- Modello: GeForce 9800 GTX
- Chip: NVIDIA GeForce 9800 GTX
- Architettura: Unified Shader Architecture
- Bus: PCI-E 2.0 x 16
Frequenze
- GraphicsClock: 675 MHz
- Processor clock: 1688 MHz
Specifiche delle memorie
- Memory size: 512 MB
- Memory type: GDDR3
- Memory clock: 1100 MHz
- Memory clock (effective): 2200 MHz
- Memory interface width: 256-bit
- Memory bandwidth: 70.4 GB/s
Cores / Texture
- CUDA: 1.1
- CUDA cores: 128
- ROPs: 16
- Texture units: 64
- RAMDACs: 400 MHz
- Decoders: H.264, MPEG 2 (SH & HD), VC-1, WMV
SLI / Crossfire
- Maximum SLI options: 3-way
Electric characteristics
- Maximum GPU temp: 105 C
- Maximum power draw: 140 W
Video features
- Multi-monitor: Si
- Maximum digital resolution: 2560 x 1600
- Maximum VGA resolution: 2048 x 1536
- Anti-Aliasing technologies: 16 x CSAA, 16 x FSAA
- HDMI: Si
HDMI version: 1.3a
Performance
- Pixel fill rate: 10.8 Gigapixels/s
- Texture fill rate: 43.2 Gigatexels/s
- Single presision compute power: 432.13 GFLOPS
Connettori esterni
- Standard display connectors: VGA, Dual Link DVI-I, HDMI
- Power connectors: 2 x 6-pin
- Audio input for HDMI: SPDIF
Dimensioni
- Larghezza: Due slot
Altre caratteristiche
- Altre features: HDCP, HybridPower Technology, PhysX, PureVideo HD
- OpenGL support: 2.1
- DirectX support: 10.0
- Shader model: 4.0
